Roland Keyboard Synthesizer fantom-08

* ZEN-Core Tones and Model Tones can import and export.
* Backup file has compatibility with FANTOM-6/7/8, but it can read the enabled features only. Expansion EXZ Series
EXSN Series
EXM Series

* The expansion are rewritable internal sound generator memory.
You can download data from the Roland Cloud and write it via a USB flash drive into the FANTOM's internal memory. Parts 16 zones (Internal + External) Scenes 128 scenes x 4 bank

* The Scenes can import and export. Tones 3,500 tones or greater
90 Drum kits or greater Tone Remain 8 zones
* When "Scene Remain Switch" enabled.
Tone Remain does not apply to VTW Organ sounds. Favorite Rating System: 4 steps (0-3) Tone Search/Scene Search Rating, Character Effects Multi-Effects: 16 systems, 90 types
Part EQ: 16 systems
Drum Part COMP: 6 systems
Insertion Effect: 2 systems, 90 types (Serial/Parallel connection selectable)
TFX: 1 system, 90 types
Input MFX: 1 system, 90 types

Chorus: 9 types
Reverb: 7 types
Master Compressor
Input Reverb: 7 types
Input EQ: 1 system Vocoder Band: 13, 20, 32
Type: Mono, Stereo
Preset Setting: 10
User Setting: 20 Scene Chain Chain: 16 Scenes x 32 Pages (Total 512 Scenes) per 1 Chain set
Set: 100
Marker: 36 (0-9, A-Z, a-z) per 1 Chain Set Pattern Sequencer MIDI Tracks 16 Group 16 Pattern 8 (per each track) Pattern Length 64 measures Recording Method Realtime recording, Step recording, TR-REC Editing Method Piano roll edit (Touch Edit/Automation support), Microscope Song 1 (per Scene) File format Original, SMF export/import supported

* PAD Sampler trigger data can be recorded. SMF Player Format SMF (Format 0/1) MIDI tracks 16 Tempo range 5-300 BPM Transpose function -5-+6 semitone Track Mute Yes Track Solo Yes A/B loop function Yes

* The pattern sequencer and SMF player can be used in each scene.
They cannot be used at the same time. Sampler - Keyboard Multisample Format 16/24-bit linear, 44.1/48 kHz, WAV/AIFF import supported. Number of Samples 2,048 Number of Multisamples 128 Sampling Time The maximum is 2 minutes 44 second (1 Sample).

* A total of approximately 256 MB (Share with Expansion titles)
* Keyboard Multisample can import and export as ZEN-Core Tone. Sampler - PAD Sampler Format 16/24-bit linear, 44.1/48 kHz, WAV/AIFF import supported Maximum Polyphony 8 Number of Samples 16 pads x 4 banks Sampling Time The maximum is 60 minutes (the equivalent of approximately 660 MB).

* A total of approximately 2 GB (including imported WAV files)
* When you use the PAD samples as KBD Wave, then you have to manipulation it. Sampler - Internal Storage space for files Size 2 GB Others Rhythm Pattern Yes Arpeggiator Yes Chord Memory Yes Motional Pad Yes PAD Mode Sample Pad,Note Pad,Partial Sw/Sel,DAW Control,Zone Mute,Zone Solo,Kbd Sw Group,Rhythm Pattern,Pattern,Variation Play,Group Play AIRA LINK * When connect to MX-1 Controllers Pitch Bend/Modulation lever *1
Assignable Switch x 2 (S1/S2)
Control knob x 8
Slider x 8
Wheel x 2 *1
Function knob x 6
Sound Modified knob x 2 *1
4 x 4 Pad

*1: 1,024 step editing support
It can be use with Cutoff, Resonance. Display Graphic Type, 5.5" (1,280 x 720 dots), backlite LCD (Color/Touch screen, Screensaver, Wallpaper support) Connectors Headphones jack: Stereo 1/4-inch phone type
MAIN OUT jacks (L/MONO, R) (1/4-inch TRS type)
SUB OUT jacks (L/MONO, R) (1/4-inch phone type)
SUB OUT STEREO (PHONES) jacks: Stereo miniature phone type PHONES Support
Mic Input jacks: 1/4 inch TRS type
Line Input jacks: (L/MONO,R) (1/4 inch phone type)
FOOT PEDAL jacks(HOLD, CTRL1, CTRL2)
MIDI connectors (IN, OUT)
USB MEMORY port
USB COMPUTER port (AUDIO/MIDI)
External Device Port: A Roland A-49 or an A-PRO series MIDI Controller can be connected. * Operation is not guaranteed if a generic MIDI device is connected. Audio Interface Max 24 bit/96 KHz
Record 16 Stereo Channel
Playback 2 Stereo Channel External Memory USB Flash drive (sold separately) Power Supply AC Adaptor Power Consumption 1,300 mAh Accessories Owner's Manual
AC adaptor Options (sold separately) Keyboard Stand:
KS-G8B, KS-11Z, KS-13, KS-20X
Pedal Switch: DP series, RPU-3
Expression Pedal: EV-5
USB Flash drive Size and Weight Width 1,393 mm
54-7/8 inches Depth 354 mm
13-15/16 inches Height 138 mm
5-7/16 inches Weight 14.8 kg
32 lbs 11 oz
