Proel power amplifier PA AMP240V4

Name: Proel power amplifier PA AMP240V4 - Universal Electronic Appliances
Price: 4999.00 AED
Availability: InStock

1 in stock

4,999.00 د.إ Inc vat

1 in stock

Add to wishlist Compare

This item is low in stock.

Item(s) left: 1

Request Quote

Category: Pro audio Brand: proel

Description

240W, Desk/Rack Mount 4 Zone mixer amplifier, 4 MIC/LINE Combo Inputs with Phantom power, Mic1 priority, 1 AUX on RCA,100V 4 Zone outputs with level controls, 70V/100V/8Ω/4Ω Main Outputs, Pre Out, Hold On and Monitor outputs, Amp In, Led meter, Low/High Tone controls

Multi-input Proel amplifier has been designed for mixing and microphone announcement distribution in PA applications.

Main features:

Four zones output at 100V selectable independently through a front keyboard
Impedance constant outputs (4W) and constant-voltage outputs (25, 70, 100 V)
Four MIC/LINE combo (XLR – ¼” jack) inputs
24V Phantom supply
Vocal activating priority MIC1 input – VOX
PRE-OUT output
AMP-IN input
RCA input
LINE OUT output
LED level meter
Hold On and Monitor outputs
Signal peak LED
Signal present LED
Telephone-line signal input
Bass and Treble EQ controls
Master output volume control
Volume controls for each zone
Five independent level controls for input signals (INPUT 1 ÷ INPUT 5)
A screw for ground wiring
Rear Power supply selector 230/117V~
Power supply: 230/117 V~ 50-60 Hz 24 V DC
Rackmount brackets included

Output power RMS	AC 240W – DC 165W
Inputs	4x MIC/LINE balanced 1x AUX (CD/TAPE/TUNER/AUX IN selectable) 1x MAIN IN (normally connected to PRE OUT) 1x TELEPHONE/EME RGENCY
Input Sensitivity	MIC: -52dBV / 600 ohm balanced (with 24V phantom) LINE: -10dBV / 100 Kohm balanced AUX: -20dBV / 47 Kohm unbalanced MAIN IN: 0dBV / 10Kohm unbalanced TELEPHONE/EMERGENCY: Variable gain - 600 ohm
Signal Output	PRE OUT (normally connected to MAIN IN)
Output Levels	PRE OUT: 1V / 600 ohm MOH 0dBV 600 ohm Variable level
Controls	1 MASTER VOLUME CONTROL 4 MIC/LINE VOLUME CONTROLS 1 AUX VOLUME CONTROL 1 TREBLE TONE CONTROL 1 BASS TONE CONTROL 4 ZONE VOLUME CONTROLS 4 ZONE SELECTORS
Loudspeakers outputs	100/70/25V -16/8/4 ohm Z1÷Z4: 100V MOH: 1W -8 ohm Variable level
Frequency response	80Hz – 16KHz (-3dB)
Distortion (THD)	< 1% (@ Pnom 1KHz)
S/N Ratio	MIC: >=dB LINE: >=75dB AUX: >=80dB
Power Supply	220V ac – 117V ac 50/60Hz 24V dc 20A
Operating temperature	0 -40ºC
Input/Output Connectors	MIC/LINE: 4x XLR/JACK 6.3mm AUX: 1x RCA L/R MAIN IN: 1x RCA PRE OUT: 1x RCA OTHERS IN/OUT: screw terminals
Power Consumption	600VA
Dimensioni (LxHxP)	420x340x88 mm – 2 rack units 19”
Peso	11.8 Kg (26.014 lb)
