KEY FEATURES
- Extended Low Frequency Range
- User Rotatable, Constant Directivity HF horn
- 8″ LF speaker and 1″ HF compression driver
- Passive 2-Way Speaker
MAIN CHARACTERISTICS
- Nominal Impedance: 8Ω
- Rated Power: 300W
- Dispersion (HxV): 90° x 60° user rotatable
- Maximum SPL: 118dB/124dB (Full-Space)
- Freq. Resp. (-6dB): 60Hz – 18.000Hz
NEXT-proaudio engineered the new PFA line of self-powered and passive speakers, specifically for installations, musicians and DJs who want state-of-the-art acoustics and electronics at a limited budget.
This speaker’s line employs fully rotatable constant directivity horns, to adjust HxV angle coverage and custom made speaker drivers.
Three high-performance powered subwoofers were designed to simplify the process of creating active 2-Way systems.
To further simplify creating active 2-Way systems the PFA15s, PFA18s and PFA18s HP use an integrated 2-channel digital amplifier to power external full-range passive speakers, for example the PFA8p, PFA12p or PFA15p.
It has never been so easy to enjoy professional audio performance made entirely in Europe at such low price!
Common to all the elements are: the Baltic birch plywood enclosures finished with a resistant black semi-matt textured paint for an extensive use, the heavy-duty power coated steel grilles and the Neutrik NL connectors on the passive versions
This speaker’s line employs fully rotatable constant directivity horns, to adjust HxV angle coverage and custom made speaker drivers.
Three high-performance powered subwoofers were designed to simplify the process of creating active 2-Way systems.
To further simplify creating active 2-Way systems the PFA15s, PFA18s and PFA18s HP use an integrated 2-channel digital amplifier to power external full-range passive speakers, for example the PFA8p, PFA12p or PFA15p.
It has never been so easy to enjoy professional audio performance made entirely in Europe at such low price!
Common to all the elements are: the Baltic birch plywood enclosures finished with a resistant black semi-matt textured paint for an extensive use, the heavy-duty power coated steel grilles and the Neutrik NL connectors on the passive versions
Technical Data
Speaker Type
Passive Two-way Speaker
Acoustical Data
Frequency Response (-6dB)
60Hz – 18.000Hz
Sensitivity (1W@1m)
93.5dB (Full-Space)
Calculated Max. SPL (Cont/Peak)
118dB/124dB (Full-Space)
Coverage Angle -6dB (HxV)
90° x 60° user rotatable
Drivers
Low Frequency
1 x 8″ (210mm)/2″ (50.5mm) VC, custom speakers
High Frequency
1 x 1″ (25mm) exit/1.75″ (44mm) voice coil, custom compression driver
Electrical Data
Recommended Amplifier
MA1700 / MA900
Rated Power
300W
Nominal Impedance
8Ω
Connectors
2 x Neutrik NL4
Enclosure
Dimensions (WxHxD)
254 x 415 x 301mm (10 x 16.34 x 11.85in)
Net Weight
10.2kg (22.5lb)
